Curved glass Cooker Hood 601 60/90cm

Extraction Rate: 550 m³/h, 65dB(A) (Noise Sound Pressure) Two Ventilation Modes Optional: vent outside by a ducting pipe installed+recycle inside with CP120 carbon filters (not included); LED Lighting: the cooker hood lamps can…

Performance

Wall mount cooker hood with flat glass in vary size 60cm,70cn,80cm and 90cm, With the hood depth 50cm to match well with cabinet when install onto the wall Tempered glass in 5mm thickness, safe enough to obstruct the grease and smell not go up but absorb by the motor at the bottom of the hood. Features with high performance motor, can easy to remove large amounts of smoke and cooking odors from the air to keep your kitchen fresh & safe to enjoy the time preparing delicious meals for your family. Control way can be with mechanical, electronic switch, LED touch control, LCD touch control for optional.

Mechanical is easy and simply operate and cost is lower, electronic switch better look and match well with full stainless steel panel, Touch control must be in glass front panel which elgent and can be have more function such as timer,booster and ok to match with DC motor with low noise. 3 speed power levels setting choose from high, medium, and low suction to suit a variety of foods and cooking. The hood hangs on the wall with 500+500mm chimney extension (adjustable height from 500mm to 980mm) 5 layers aluminum filter capture the grease well and easy to clean by dishwasher

Operating Mode

With flexible choice between recirculation or direct air exhausting. 1.Recirculating mode: Charcoal filters are necessary if your area is not allowed to install outdoor exhaust pipe.Replaced every 2 to 4 months depending on using frequency. Charcoal filter is optional so our product not put it as standard parts,but we can offer as spare parts which you can easy to buy and install by yourself. 2. Direct air exhausting mode:Used as a ducting vent cooker hood with a duct pipe 150mm in diameter. Our cooker hood along with duct pipe in 1.5M or 2M, you also can buy it as spare parts easily from shops only need to with the right diameter.

Energy-Saving Light

With the included two LED lights can keep your cooking space bright enough. Mounted directly below the wall mount range hood, cook, and see better in the dark.

Elegant Appearance

Slim controal panel is perfect matching kinds of kitchen with this wall mounted hood..

Material: SS430, Tempered glass

Airflow: 550 m³/h

Motor Type: 1x100W

Control Type: Push button

Level of Speed: 3

Lighting: 2x2W LED lamp

Filter Type: 1pcs Aluminum filter

Chimney extension: 500+500mm

Air Outlet: 150mm

Loading QTY(20/40/40HQ): 204/432/503(60cm) / 136/280/322(90cm)



Option Features:

Size: 50/60/70/90cm

Color: Black / White painted body

Smoke grey tempered glass

Switch: Electronic switch/Touch control

Motor: 350/750/1000m3/h

650/900m3/h-DC motor

Filter function: Baffle filter/Charcoal filter/VC filter
